EDR-3000 IM02602003E
Front Panel
www.eaton.com 146
1 2 3
5
76 9 10
RS232 Interface
(
PowerPort-E
Connection)
ACK/RST-key
INFO Key
(Signals/Messages)
Control
Softkeys
DisplayLED »System OK« Programmable LEDs
Protective
Device
8
OK-key
