Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Loading of Device Data When Using PowerPort-E
Start the PowerPort-E application .
Make sure the connection has been established properly.
Connect your PC with the device via a null modem cable .
Select »Receiving Data From The Device« in the »Device« menu.
Restoring Device Data When Using PowerPort-E
By selecting the »Transfer only modified parameters into the device« button,
only modified parameters are transmitted into the device.
Parameter modifications are indicated by a red “star symbol” in front of the
parameter.
The star symbol (in the device tree window) indicates that parameters in the
opened file (within PowerPort-E) differ from parameters stored on your local
hard disk.
By selecting the »Transfer only modified parameters into the device« button,
the User can transmit all parameters that are marked by this symbol.
If a parameter file is saved on the local hard drive, these parameters are no
longer classified to be modified and cannot be transmitted via the »Transfer
only modified parameters into the device« button.
In case the User has loaded and modified a parameter file from the device and
saved it to the local hard drive without transferring the parameters into the
device beforehand, the User cannot use the »Transfer only modified
parameters into the device« button. In this case, use the »Transfer all
parameters into the device« button.
The »Transfer only modified parameters into the device« button only works if
modified parameters are available in the PowerPort-E application.
In contrast, all parameters of the device are transferred when the »Transfer all
parameters into the device« button is pressed (provided all device parameters
are valid).
www.eaton.com 166
