TCP/IP Settings

Warning: Mixing up IP Addresses

(In case there is more than one protective device within the TCP/IP network or

establishing an unintentional wrong connection to a protective device based on a wrong

entered IP address.

Transferring parameters into the wrong protective device might lead to death, personal

injury, or damage of electrical equipment.

In order to prevent faulty connections, the User MUST document and maintain a list with

the IP addresses of any switchboard/protective devices.

The User MUST double check the IP addresses of the connection that is to be

established. That means, the User MUST first read out the IP address at the HMI of

the device (within menu [Device para/TCP IP]) then compare the IP address with the

list. If the addresses are identical, establish the connection. If they are not, DO NOT

establish the connection.

Within

»Device Para / TCP/IP«

menu, the TCP/IP settings have to be set.

The first-time setting of the TCP/IP Parameters can be done at the panel (HMI) only.

Establishing a connection via TCP/IP to the device is only possible if the device

is equipped with an Ethernet interface (RJ45).

Contact your IT administrator in order to establish the network connection.

Set the TCP/IP Parameters:

Call up

»Device parameter/TCP/IP«

at the HMI (panel) and set the following parameters:

TCP/IP address;

Subnetmask; and

Gateway.
