Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Name Description
Bkr.CES Fail TripCmd Signal: Command Execution Supervision: Command execution failed because trip command is pending.
Bkr.CES SwitchgDir Signal: Command Execution Supervision respectivly Switching Direction Control: This signal becomes true, if
a switch command is issued even though the switchgear is already in the requested position. Example: A
switchgear that is already OPEN should be switched OPEN again (doubly). The same applies to CLOSE
commands.
Bkr.CES CLOSE d OPEN Signal: Command Execution Supervision: CLOSE Command during a pending OPEN Command.
Bkr.CES SG not ready Signal: Command Execution Supervision: Switchgear not ready
Bkr.CES Field Interl Signal: Command Execution Supervision: Switching Command not executed because of field interlocking.
Bkr.CES SyncTimeout Signal: Command Execution Supervision: Switching Command not executed. No Synchronization signal while
t-sync was running.
Bkr.CES SG removed Signal: Command Execution Supervision: Switching Command unsuccessful, Switchgear removed.
Bkr.Prot CLOSE Signal: CLOSE command issued by the Prot module
Bkr.TripCmd Signal: Trip Command
Bkr.Ack TripCmd Signal: Acknowledge Trip Command
Bkr.Bwear Slow Breaker Signal: Slow Breaker Alarm
Bkr.Res Bwear Sl Breaker Signal: Resetting the slow breaker alarm
Bkr.CLOSE Cmd Signal: CLOSE command issued to the switchgear. Depending on the setting the signal may include the
CLOSE command of the Prot module.
Bkr.OPEN Cmd Signal: OPEN command issued to the switchgear. Depending on the setting the signal may include the OPEN
command of the Prot module.
Bkr.CLOSE Cmd manual Signal: CLOSE Cmd manual
Bkr.OPEN Cmd manual Signal: OPEN Cmd manual
Bkr.Sync CLOSE request Signal: Synchronous CLOSE request
Bkr.CinBkr-52a-I Module Input State: Feed-back signal of the Bkr (52a)
Bkr.CinBkr-52b-I Module Input State: Feed-back signal of the Bkr. (52b)
Bkr.Ready-I Module Input State: Breaker Ready
Bkr.Sys-in-Sync-I State of the module input: This signals has to become true within the synchronization time. If not, switching is
unsuccessful.
Bkr.Ack TripCmd-I State of the module input: Acknowledgment Signal (only for automatic acknowledgment). Module input signal
Bkr.Interl CLOSE1-I State of the module input: Interlocking of the CLOSE command
Bkr.Interl CLOSE2-I State of the module input: Interlocking of the CLOSE command
Bkr.Interl CLOSE3-I State of the module input: Interlocking of the CLOSE command
Bkr.Interl OPEN1-I State of the module input: Interlocking of the OPEN command
Bkr.Interl OPEN2-I State of the module input: Interlocking of the OPEN command
Bkr.Interl OPEN3-I State of the module input: Interlocking of the OPEN command
Bkr.SC CLOSE-I State of the module input: Switching CLOSE Command, e.g. the state of the Logics or the state of the digital
input
Bkr.SC OPEN-I State of the module input: Switching OPEN Command, e.g. the state of the Logics or the state of the digital
input
Bkr.Operations Alarm Signal: Service Alarm, too many Operations
www.eaton.com 705
