EDR-3000 IM02602003E
Name Description
Bkr.Isum Intr trip: IA Signal: Maximum permissible Summation of the interrupting (tripping) currents exceeded: IA
Bkr.Isum Intr trip: IB Signal: Maximum permissible Summation of the interrupting (tripping) currents exceeded: IB
Bkr.Isum Intr trip: IC Signal: Maximum permissible Summation of the interrupting (tripping) currents exceeded: IC
Bkr.Isum Intr trip Signal: Maximum permissible Summation of the interrupting (tripping) currents exceeded in at least one
phase.
Bkr.Res TripCmdCr Signal: Resetting of the Counter: total number of trip commands
Bkr.Res Isum trip Signal: Reset summation of the tripping currents
Bkr.WearLevel Alarm Signal: Breaker Wear curve Alarm
Bkr.WearLevel Lockout Signal: Breaker Wear Curve Lockout Level
Bkr.Res Bwear Curve Signal: Reset of the Breaker Wear maintenance curve.
Bkr.Isum Intr ph Alm Signal: Alarm, the per hour Sum (Limit) of interrupting currents has been exceeded.
Bkr.Res Isum Intr ph Alm Signal: Reset of the Alarm, "the per hour Sum (Limit) of interrupting currents has been exceeded".
50P[1].Active Signal: Active
50P[1].ExBlo Signal: External Blocking
50P[1].Rvs Blo Signal: Reverse Blocking
50P[1].Blo TripCmd Signal: Trip Command blocked
50P[1].ExBlo TripCmd Signal: External Blocking of the Trip Command
50P[1].Pickup IA Signal: Pickup IA
50P[1].Pickup IB Signal: Pickup IB
50P[1].Pickup IC Signal: Pickup IC
50P[1].Pickup Signal: Pickup
50P[1].Trip Phase A Signal: General Trip Phase A
50P[1].Trip Phase B Signal: General Trip Phase B
50P[1].Trip Phase C Signal: General Trip Phase C
50P[1].Trip Signal: Trip
50P[1].TripCmd Signal: Trip Command
50P[1].DefaultSet Signal: Default Parameter Set
50P[1].AdaptSet 1 Signal: Adaptive Parameter 1
50P[1].AdaptSet 2 Signal: Adaptive Parameter 2
50P[1].AdaptSet 3 Signal: Adaptive Parameter 3
50P[1].AdaptSet 4 Signal: Adaptive Parameter 4
50P[1].ExBlo1-I Module Input State: External Blocking1
50P[1].ExBlo2-I Module Input State: External Blocking2
50P[1].ExBlo TripCmd-I Module Input State: External Blocking of the Trip Command
50P[1].Rvs Blo-I Module Input State: Reverse Blocking
50P[1].AdaptSet1-I Module Input State: Adaptive Parameter1
50P[1].AdaptSet2-I Module Input State: Adaptive Parameter2
www.eaton.com 706
