Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Parameter Description Setting range Default Menu path
LED Active Color The LED lights up in this color if the state of the OR-
assignment of the signals is true.
Green,
Red,
Red flash,
Green flash,
-
Red [Device Para
/LEDs
/LEDs group A
/LED 2]
LED Inactive Color The LED lights up in this color if the state of the OR-
assignment of the signals is false.
Green,
Red,
Red flash,
Green flash,
-
- [Device Para
/LEDs
/LEDs group A
/LED 2]
Assignment 1 Assignment 1..n, Assignment
List
51X[1].Trip [Device Para
/LEDs
/LEDs group A
/LED 2]
Inverting 1 Inverting of the state of the assigned signal. Inactive,
Active
Inactive [Device Para
/LEDs
/LEDs group A
/LED 2]
Assignment 2 Assignment 1..n, Assignment
List
51R[1].Trip [Device Para
/LEDs
/LEDs group A
/LED 2]
Inverting 2 Inverting of the state of the assigned signal. Inactive,
Active
Inactive [Device Para
/LEDs
/LEDs group A
/LED 2]
Assignment 3 Assignment 1..n, Assignment
List
-.- [Device Para
/LEDs
/LEDs group A
/LED 2]
Inverting 3 Inverting of the state of the assigned signal. Inactive,
Active
Inactive [Device Para
/LEDs
/LEDs group A
/LED 2]
www.eaton.com 131
