Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Parameter Description Setting range Default Menu path
Assignment 1 Assignment 1..n, Assignment
List
50P[1].Trip [Device Para
/LEDs
/LEDs group A
/LED 3]
Inverting 1 Inverting of the state of the assigned signal. Inactive,
Active
Inactive [Device Para
/LEDs
/LEDs group A
/LED 3]
Assignment 2 Assignment 1..n, Assignment
List
-.- [Device Para
/LEDs
/LEDs group A
/LED 3]
Inverting 2 Inverting of the state of the assigned signal. Inactive,
Active
Inactive [Device Para
/LEDs
/LEDs group A
/LED 3]
Assignment 3 Assignment 1..n, Assignment
List
-.- [Device Para
/LEDs
/LEDs group A
/LED 3]
Inverting 3 Inverting of the state of the assigned signal. Inactive,
Active
Inactive [Device Para
/LEDs
/LEDs group A
/LED 3]
Assignment 4 Assignment 1..n, Assignment
List
-.- [Device Para
/LEDs
/LEDs group A
/LED 3]
Inverting 4 Inverting of the state of the assigned signal. Inactive,
Active
Inactive [Device Para
/LEDs
/LEDs group A
/LED 3]
Assignment 5 Assignment 1..n, Assignment
List
-.- [Device Para
/LEDs
/LEDs group A
/LED 3]
