EDR-3000 IM02602003E
Device Planning Parameters of the 50P Module
Parameter Description Options Default Menu path
Mode Mode 50P[1]: Non-directional
50P[2]: Non-directional
50P[3]: Do not use,
Non-directional
Non-directional [Device Planning]
Global Protection Parameters of the 50P Module
Parameter Description Setting range Default Menu path
ExBlo1 External blocking of the module, if blocking is activated
(allowed) within a parameter set and if the state of the
assigned signal is true.
1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/I-Prot
/50P[1]]
ExBlo2 External blocking of the module, if blocking is activated
(allowed) within a parameter set and if the state of the
assigned signal is true.
1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/I-Prot
/50P[1]]
ExBlo TripCmd External blocking of the Trip Command of the module/the
element, if blocking is activated (allowed) within a
parameter set and if the state of the assigned signal is
true.
1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/I-Prot
/50P[1]]
Rvs Blo Reverse Blocking, if Reverse Blocking is activated
(allowed) within a parameter set and if the state of the
assigned signal is true.
1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/I-Prot
/50P[1]]
AdaptSet 1 Assignment Adaptive Parameter 1 AdaptSet -.- [Protection Para
/Global Prot Para
/I-Prot
/50P[1]]
AdaptSet 2 Assignment Adaptive Parameter 2 AdaptSet -.- [Protection Para
/Global Prot Para
/I-Prot
/50P[1]]
