Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
50P Module Signals (Output States)
Signal Description
Active Signal: Active
ExBlo Signal: External Blocking
Rvs Blo Signal: Reverse Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Pickup IA Signal: Pickup IA
Pickup IB Signal: Pickup IB
Pickup IC Signal: Pickup IC
Pickup Signal: Pickup
Trip Phase A Signal: General Trip Phase A
Trip Phase B Signal: General Trip Phase B
Trip Phase C Signal: General Trip Phase C
Trip Signal: Trip
TripCmd Signal: Trip Command
Active AdaptSet Active Adaptive Parameter
DefaultSet Signal: Default Parameter Set
AdaptSet 1 Signal: Adaptive Parameter 1
AdaptSet 2 Signal: Adaptive Parameter 2
AdaptSet 3 Signal: Adaptive Parameter 3
AdaptSet 4 Signal: Adaptive Parameter 4
www.eaton.com 411
