Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
AR Start Functions
Name Description
-.- No assignment
50P[1].TripCmd Signal: Trip Command
50P[2].TripCmd Signal: Trip Command
50P[3].TripCmd Signal: Trip Command
51P[1].TripCmd Signal: Trip Command
51P[2].TripCmd Signal: Trip Command
51P[3].TripCmd Signal: Trip Command
50X[1].TripCmd Signal: Trip Command
50X[2].TripCmd Signal: Trip Command
51X[1].TripCmd Signal: Trip Command
51X[2].TripCmd Signal: Trip Command
50R[1].TripCmd Signal: Trip Command
50R[2].TripCmd Signal: Trip Command
51R[1].TripCmd Signal: Trip Command
51R[2].TripCmd Signal: Trip Command
46[1].TripCmd Signal: Trip Command
46[2].TripCmd Signal: Trip Command
ExP[1].TripCmd Signal: Trip Command
ExP[2].TripCmd Signal: Trip Command
ExP[3].TripCmd Signal: Trip Command
ExP[4].TripCmd Signal: Trip Command
www.eaton.com 537

Eaton EDR 3000 Specifications

General

Brand	Eaton
Model	EDR 3000
Category	Relays
Language	English
