Eaton EDR 3000 User Manual

EDR-3000 IM02602003E
Device Planning Parameters of the External Protection Module
Parameter Description Options Default Menu path
Mode Mode Do not use,
Use
Do not use [Device Planning]
Global Protection Parameters of the External Protection Module
Parameter Description Setting range Default Menu path
ExBlo1 External blocking of the module, if blocking is activated
(allowed) within a parameter set and if the state of the
assigned signal is true.
1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
ExBlo2 External blocking of the module, if blocking is activated
(allowed) within a parameter set and if the state of the
assigned signal is true.
1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
ExBlo TripCmd External blocking of the Trip Command of the module/the
element, if blocking is activated (allowed) within a
parameter set and if the state of the assigned signal is
true.
1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
Alarm Assignment for External Alarm 1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
Trip External trip of the Bkr. if the state of the assigned signal
is true.
1..n, Assignment
List
-.- [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
