EDR-3000 IM02602003E
External Protection Module Input States
Name Description Assignment via
ExBlo1-I Module Input State: External Blocking1 [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
ExBlo2-I Module Input State: External Blocking2 [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
ExBlo TripCmd-I Module Input State: External Blocking of the Trip Command [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
Alarm-I Module Input State: Alarm [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
Trip-I Module Input State: Trip [Protection Para
/Global Prot Para
/ExP
/ExP[1]]
External Protection Module Signals (Output States)
Signal Description
Active Signal: Active
ExBlo Signal: External Blocking
Blo TripCmd Signal: Trip Command blocked
ExBlo TripCmd Signal: External Blocking of the Trip Command
Alarm Signal: Alarm
Trip Signal: Trip
TripCmd Signal: Trip Command
