101
(SFP+_DIS_P38)
0: transceiver is under transmit enable (Default)
5
Disable* P36 SFP28
(SFP+_DIS_P35)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
4
Disable* P35 SFP28
(SFP+_DIS_P33)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
3
Disable* P34 SFP28
(SFP+_DIS_P34)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
2
Disable* P33 SFP28
(SFP+_DIS_P30)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
1
Disable* P32 SFP28
(SFP+_DIS_P36)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
0
Disable* P31 SFP28
(SFP+_DIS_P29)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5.12.2.22. Offset 0x15 Module Disable-2 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7
Disable* P46 SFP28
(SFP+_DIS_P47)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
6
Disable* P45 SFP28
(SFP+_DIS_P43)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5
Disable* P44 SFP28
(SFP+_DIS_P45)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
4
Disable* P43 SFP28
(SFP+_DIS_P44)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
3
Disable* P42 SFP28
(SFP+_DIS_P37)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
2
Disable* P41 SFP28
(SFP+_DIS_P42)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
1
Disable* P40 SFP28
(SFP+_DIS_P41)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
0
Disable* P39 SFP28
(SFP+_DIS_P40)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5.12.2.23. Offset 0x16 Module Disable-3 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:4
Reserve
NA
NA
