Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
104
0: transceiver is working well
1
Fault* P32 SFP28
(SFP+_FLT_P36)
R
1
1: transceiver Fault
0: transceiver is working well
0
Fault* P31 SFP28
(SFP+_FLT_P29)
R
1
1: transceiver Fault
0: transceiver is working well
5.12.2.28. Offset 0x1B Module Fault-2 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Fault* P46 SFP28
(SFP+_FLT_P47)
R
1
1: transceiver Fault
0: transceiver is working well
6
Fault* P45 SFP28
(SFP+_FLT_P43)
R
1
1: transceiver Fault
0: transceiver is working well
5
Fault* P44 SFP28
(SFP+_FLT_P45)
R
1
1: transceiver Fault
0: transceiver is working well
4
Fault* P43 SFP28
(SFP+_FLT_P44)
R
1
1: transceiver Fault
0: transceiver is working well
3
Fault* P42 SFP28
(SFP+_FLT_P37)
R
1
1: transceiver Fault
0: transceiver is working well
2
Fault* P41 SFP28
(SFP+_FLT_P42)
R
1
1: transceiver Fault
0: transceiver is working well
1
Fault* P40 SFP28
(SFP+_FLT_ P41)
R
1
1: transceiver Fault
0: transceiver is working well
0
Fault* P39 SFP28
(SFP+_FLT_P40)
R
1
1: transceiver Fault
0: transceiver is working well
5.12.2.29. Offset 0x1C Module Fault-3 (Read Only)
Bit
Name
R/W
Reset Value
Description
7:4
Reserve
NA
NA
3
Fault* P58 SFP+
(TX_FAULT_FX1)
R
1
1: transceiver Fault
0: transceiver is working well
2
Fault* P57 SFP+
(TX_FAULT_FX0)
R
1
1: transceiver Fault
0: transceiver is working well
1
Fault* P48 SFP28
(SFP+_FLT_P46)
R
1
1: transceiver Fault
0: transceiver is working well
0
Fault* P47 SFP28
(SFP+_FLT_P48)
R
1
1: transceiver Fault
0: transceiver is working well
