Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
107
3
DIAG_Blinking_R
R/W
0
1: DIAG_R Blinking ON
0: DIAG_R Blinking OFF (Default)
2
DIAG_B
R/W
1
1: DIAG_B LED OFF (Default)
0: DIAG_B LED ON
1
DIAG_G
R/W
1
1: DIAG_G LED OFF (Default)
0: DIAG_G LED ON
0
DIAG_R
R/W
1
1: DIAG_R LED OFF (Default)
0: DIAG_R LED ON
5.12.2.35. Offset 0x25 System LED -5 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
LOC_Blinking_B
R/W
0
1: LOC_B Blinking ON
0: LOC_B Blinking OFF (Default)
4
LOC_Blinking_G
R/W
0
1: LOC_G Blinking ON
0: LOC_G Blinking OFF (Default)
3
LOC_Blinking_R
R/W
0
1: LOC_R Blinking ON
0: LOC_R Blinking OFF (Default)
2
LOC_B
R/W
1
1: LOC_B LED OFF (Default)
0: LOC_B LED ON
1
LOC_G
R/W
1
1: LOC_G LED OFF (Default)
0: LOC_G LED ON
0
LOC_R
R/W
1
1: LOC_R LED OFF (Default)
0: LOC_R LED ON
5.12.2.36. Offset 0x26 system LED -6 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
System_Blinking_B
R/W
0
1: System_B Blinking ON
0: System_B Blinking OFF (Default)
4
System_Blinking_G
R/W
0
1: System_G Blinking ON
0: System_G Blinking OFF (Default)
3
System_Blinking_R
R/W
0
1: System_R Blinking ON
0: System_R Blinking OFF (Default)
2
System_B
R/W
1
1: System_B LED OFF (Default)
0: System_B LED ON
1
System_G
R/W
1
1: System_G LED OFF (Default)
0: System_G LED ON
0
System_R
R/W
1
1: System_R LED OFF (Default)
0: System_R LED ON
