Edge-Core AS7326-56X - Page 106

EDGECORE NETWORKS CORPORATION 2018
106
status signals (Default)
0: PSU2 status by S/W.
5
PSU2_Blinking_B
R/W
0
1: PSU2_B Blinking ON
0: PSU2_B Blinking OFF (Default)
4
PSU2_Blinking_G
R/W
0
1: PSU2_G Blinking ON
0: PSU2_G Blinking OFF (Default)
3
PSU2_Blinking_R
R/W
0
1: PSU2_R Blinking ON
0: PSU2_R Blinking OFF (Default)
2
PSU2_B
R/W
1
1: PSU2_B LED OFF (Default)
0: PSU2_B LED ON
1
PSU2_G
R/W
0
1: PSU2_G LED OFF (Default)
0: PSU2_G LED ON
0
PSU2_R
R/W
1
1: PSU2_R LED OFF (Default)
0: PSU2_R LED ON
5.12.2.33. Offset 0x23 System LED -3 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7
Reserve
NA
NA
6
FAN _Control
R/W
1
1: Auto detect FAN status based on FAN hardware
status signals (Default)
0: FAN status by S/W.
5
FAN_Blinking_B
R/W
0
1: FAN_B Blinking ON
0: FAN_B Blinking OFF (Default)
4
FAN_Blinking_G
R/W
0
1: FAN_G Blinking ON
0: FAN_G Blinking OFF (Default)
3
FAN_Blinking_R
R/W
0
1: FAN_R Blinking ON
0: FAN_R Blinking OFF (Default)
2
FAN_B
R/W
1
1: FAN_B LED OFF (Default)
0: FAN_B LED ON
1
FAN_G
R/W
0
1: FAN_G LED OFF (Default)
0: FAN_G LED ON
0
FAN_R
R/W
1
1: FAN_R LED OFF (Default)
0: FAN_R LED ON
5.12.2.34. Offset 0x24 System LED -4 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
DIAG_Blinking_B
R/W
0
1: DIAG_B Blinking ON
0: DIAG_B Blinking OFF (Default)
4
DIAG_Blinking_G
R/W
0
1: DIAG_G Blinking ON
0: DIAG_G Blinking OFF (Default)
