Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
109
Pin
Net name
IN/ OUT
C2
P3_Lane2_LED_B
OUT
C3
P46_Lane1_LED_R
OUT
D1
P2_Lane1_LED_R
OUT
D2
P2_Lane1_LED_B
OUT
D3
SFP+_RXLOS_P2
IN
D4
SFP+_MOD_ABS_P2
IN
E1
P3_Lane2_LED_R
OUT
E2
P2_Lane1_LED_G
OUT
E3
SFP+_DIS_P3
OUT
E4
SFP+_FLT_P3
IN
E5
SFP+_DIS_P31
OUT
F1
P4_Lane3_LED_B
OUT
F2
P4_Lane3_LED_G
OUT
F3
P8_Lane3_LED_B
OUT
F4
SFP+_RXLOS_P3
IN
F5
SFP+_FLT_P31
IN
F6
IP_LED_DATA2
IN
G1
P4_Lane3_LED_R
OUT
G2
P7_Lane2_LED_G
OUT
G3
SFP+_MOD_ABS_P3
IN
G4
SFP+_FLT_P2
IN
G5
SFP+_MOD_ABS_P28
IN
G6
SFP+_MOD_ABS_P21
IN
G7
SFP+_RXLOS_P21
IN
H1
P7_Lane2_LED_B
OUT
H2
P8_Lane3_LED_G
OUT
H3
SFP+_RXLOS_P4
IN
H4
SFP+_MOD_ABS_P4
IN
H5
SFP+_DIS_P25
OUT
H6
SFP+_FLT_P24
IN
J1
P1_Lane0_LED_B
OUT
J2
P8_Lane3_LED_R
OUT
J3
SFP+_FLT_P4
IN
J4
SFP+_DIS_P4
OUT
J5
SFP+_RXLOS_P27
IN
K1
P1_Lane0_LED_R
OUT
