Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
110
K2
P7_Lane2_LED_R
OUT
K3
SFP+_RXLOS_P7
IN
K4
SFP+_MOD_ABS_P7
IN
K5
SFP+_DIS_P2
OUT
L1
SFP+_DIS_P8
OUT
L2
P1_Lane0_LED_G
OUT
L3
SFP+_FLT_P8
IN
L4
SFP+_RXLOS_P1
IN
L5
SFP+_MOD_ABS_P32
IN
L6
SFP+_FLT_P25
IN
M1
P5_Lane0_LED_B
OUT
M2
P12_Lane3_LED_B
OUT
M3
SFP+_MOD_ABS_P1
IN
M4
SFP+_DIS_P1
OUT
M5
SFP+_FLT_P28
IN
M6
SFP+_DIS_P18
OUT
N1
P5_Lane0_LED_G
OUT
N2
P12_Lane3_LED_G
OUT
N3
SFP+_FLT_P1
IN
N4
SFP+_RXLOS_P8
IN
N5
SFP+_DIS_P28
OUT
P1
P5_Lane0_LED_R
OUT
P2
P12_Lane3_LED_R
OUT
P3
SFP+_MOD_ABS_P8
IN
P4
SFP+_FLT_P7
IN
R1
P6_Lane1_LED_B
OUT
R2
P6_Lane1_LED_G
OUT
R3
SFP+_DIS_P7
OUT
T2
P6_Lane1_LED_R
OUT
T3
SFP+_MOD_ABS_P12
IN
A10
IP_LED_CLK1
IN
A11
P23_Lane2_LED_B
OUT
A12
P22_Lane1_LED_G
OUT
A13
IP_LED_DATA1
IN
A14
SFP+_RXLOS_P25
IN
A15
P22_Lane1_LED_B
OUT
A17
P18_Lane1_LED_G
OUT

Edge-Core AS7326-56X Specifications

General

Brand	Edge-Core
Model	AS7326-56X
Category	Switch
Language	English
