Edge-Core AS7326-56X - Page 111

EDGECORE NETWORKS CORPORATION 2018
111
A2
P29_Lane0_LED_G
OUT
A4
P32_Lane3_LED_R
OUT
A5
P36_Lane3_LED_R
OUT
A6
P36_Lane3_LED_B
OUT
A7
P32_Lane3_LED_B
OUT
A8
P28_Lane3_LED_R
OUT
A9
P31_Lane2_LED_B
OUT
B1
P3_Lane2_LED_G
OUT
B10
P31_Lane2_LED_G
OUT
B11
P22_Lane1_LED_R
OUT
B12
P23_Lane2_LED_G
OUT
B13
P21_Lane0_LED_R
OUT
B14
P21_Lane0_LED_G
OUT
B15
P21_Lane0_LED_B
OUT
B16
P18_Lane1_LED_R
OUT
B18
P35_Lane2_LED_R
OUT
B3
P25_Lane0_LED_B
OUT
B4
P25_Lane0_LED_G
OUT
B5
P25_Lane0_LED_R
OUT
B6
P31_Lane2_LED_R
OUT
B7
P36_Lane3_LED_G
OUT
B8
P32_Lane3_LED_G
OUT
B9
P28_Lane3_LED_B
OUT
C10
P19_Lane2_LED_G
OUT
C11
P27_Lane2_LED_R
OUT
C12
P27_Lane2_LED_B
OUT
C13
N/A
C14
P30_Lane1_LED_B
OUT
C15
P30_Lane1_LED_R
OUT
C4
P46_Lane1_LED_G
OUT
C5
P43_Lane2_LED_R
OUT
C6
P43_Lane2_LED_B
OUT
C7
P40_Lane3_LED_R
OUT
C8
P40_Lane3_LED_B
OUT
C9
P29_Lane0_LED_R
OUT
D10
P20_Lane3_LED_B
OUT
D11
P28_Lane3_LED_G
OUT
