Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
118
0x45
SFP28 RGB LED -38
Read &Write
0x07
5.12.4.1. Offset 0x01 CPLD version (Read Only)
Bit
Name
R/W
Reset Value
Description
7:0
CPLD_ver[7:0]
R
0x03
CPLD version
5.12.4.2. Offset 0x02 CPLD interrupt(Read & Write)
Bit
Name
R/W
Reset Value
Description
7:1
Reserved
NA
NA
0
CPLD2_INT
R/W
1
1:No interrupt(Default)
0: Sent interrupt request to CPLD1
5.12.4.3. Offset 0x03 Module Fault-1 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Fault* P8 SFP28
(SFP+_FLT_P12)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
6
Fault* P7 SFP28
(SFP+_FLT_P5)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
5
Fault* P6 SFP28
(SFP+_FLT_P1)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
4
Fault* P5 SFP28
(SFP+_FLT_P7)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
3
Fault* P4 SFP28
(SFP+_FLT_P8)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
2
Fault* P3 SFP28
(SFP+_FLT_P4)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
1
Fault* P2 SFP28
(SFP+_FLT_P2)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
0
Fault* P1 SFP28
(SFP+_FLT_P3)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
5.12.4.4. Offset 0x04 Module Fault-2 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Fault* P16 SFP28
(SFP+_FLT_P20)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
