Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
119
6
Fault* P15 SFP28
(SFP+_FLT_P16)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
5
Fault* P14 SFP28
(SFP+_FLT_P14)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
4
Fault* P13 SFP28
(SFP+_FLT_P15)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
3
Fault* P12 SFP28
(SFP+_FLT_P11)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
2
Fault* P11 SFP28
(SFP+_FLT_P9)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
1
Fault* P10 SFP28
(SFP+_FLT_P10)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
0
Fault* P9 SFP28
(SFP+_FLT_P6)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
5.12.4.5. Offset 0x05 Module Fault-3 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Fault* P24 SFP28
(SFP+_FLT_P23)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
6
Fault* P23 SFP28
(SFP+_FLT_P21)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
5
Fault* P22 SFP28
(SFP+_FLT_P22)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
4
Fault* P21 SFP28
(SFP+_FLT_P18)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
3
Fault* P20 SFP28
(SFP+_FLT_P24)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
2
Fault* P19 SFP28
(SFP+_FLT_P17)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
1
Fault* P18 SFP28
(SFP+_FLT_P13)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
0
Fault* P17 SFP28
(SFP+_FLT_P19)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
5.12.4.6. Offset 0x06 Module Fault-4 (Read Only)
Bit
Name
R/W
Reset Value
Description
