Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
120
7:6
Reserved
NA
NA
5
Fault* P30 SFP28
(SFP+_FLT_P25)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
4
Fault* P29 SFP28
(SFP+_FLT_P31)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
3
Fault* P28 SFP28
(SFP+_FLT_P32)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
2
Fault* P27 SFP28
(SFP+_FLT_P28)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
1
Fault* P26 SFP28
(SFP+_FLT_P26)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
0
Fault* P25 SFP28
(SFP+_FLT_P27)
R
1
1: transceiver Fault(Default)
0: transceiver is working well
5.12.4.7. Offset 0x07 Module Disable-1 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7
Disable* P8 SFP28
(SFP+_DIS_P12)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
6
Disable* P7 SFP28
(SFP+_DIS_P5)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5
Disable* P6 SFP28
(SFP+_DIS_P1)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
4
Disable* P5 SFP28
(SFP+_DIS_P7)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
3
Disable* P4 SFP28
(SFP+_DIS_P8)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
2
Disable* P3 SFP28
(SFP+_DIS_P4)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
1
Disable* P2 SFP28
(SFP+_DIS_P2)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
0
Disable* P1 SFP28
(SFP+_DIS_P3)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5.12.4.8. Offset 0x08 Module Disable-2 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7
Disable* P16 SFP28
(SFP+_DIS_P20)
R/W
0
1: transceiver is under transmit disable
