Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
121
0: transceiver is under transmit enable (Default)
6
Disable* P15 SFP28
(SFP+_DIS_P16)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5
Disable* P14 SFP28
(SFP+_DIS_P14)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
4
Disable* P13 SFP28
(SFP+_DIS_P15)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
3
Disable* P12 SFP28
(SFP+_DIS_P11)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
2
Disable* P11 SFP28
(SFP+_DIS_P9)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
1
Disable* P10 SFP28
(SFP+_DIS_P10)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
0
Disable* P9 SFP28
(SFP+_DIS_P6)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5.12.4.9. Offset 0x09 Module Disable-3 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7
Disable* P24 SFP28
(SFP+_DIS_P23)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
6
Disable* P23 SFP28
(SFP+_DIS_P21)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5
Disable* P22 SFP28
(SFP+_DIS_P22)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
4
Disable* P21 SFP28
(SFP+_DIS_P18)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
3
Disable* P20 SFP28
(SFP+_DIS_P24)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
2
Disable* P19 SFP28
(SFP+_DIS_P17)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
1
Disable* P18 SFP28
(SFP+_DIS_P13)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
0
Disable* P17 SFP28
(SFP+_DIS_P19)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
