5.12.4.10. Offset 0x0A Module Disable-4 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserved
NA
NA
5
Disable* P30 SFP28
(SFP+_DIS_P25)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
4
Disable* P29 SFP28
(SFP+_DIS_P31)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
3
Disable* P28 SFP28
(SFP+_DIS_P32)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
2
Disable* P27 SFP28
(SFP+_DIS_P28)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
1
Disable* P26 SFP28
(SFP+_DIS_P26)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
0
Disable* P25 SFP28
(SFP+_DIS_P27)
R/W
0
1: transceiver is under transmit disable
0: transceiver is under transmit enable (Default)
5.12.4.11. Offset 0x0B Module RX_LOSS-1 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
RX_LOSS* P8 SFP28
(SFP+_RXLOS_P12)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
6
RX_LOSS* P7 SFP28
(SFP+_RXLOS_P5)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
5
RX_LOSS* P6 SFP28
(SFP+_RXLOS_P1)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
4
RX_LOSS* P5 SFP28
(SFP+_RXLOS_P7)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
3
RX_LOSS* P4 SFP28
(SFP+_RXLOS_P8)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
2
RX_LOSS* P3 SFP28
(SFP+_RXLOS_P4)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
1
RX_LOSS* P2 SFP28
(SFP+_RXLOS_P2)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
0
RX_LOSS* P1 SFP28
(SFP+_RXLOS_P3)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
