Edge-Core AS7326-56X - Page 123

EDGECORE NETWORKS CORPORATION 2018
123
5.12.4.12. Offset 0x0C Module RX_LOSS-2 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
RX_LOSS* P16 SFP28
(SFP+_RXLOS_P20)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
6
RX_LOSS* P15 SFP28
(SFP+_RXLOS_P16)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
5
RX_LOSS* P14 SFP28
(SFP+_RXLOS_P14)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
4
RX_LOSS* P13 SFP28
(SFP+_RXLOS_P15)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
3
RX_LOSS* P12 SFP28
(SFP+_RXLOS_P11)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
2
RX_LOSS* P11 SFP28
(SFP+_RXLOS_P9)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
1
RX_LOSS* P10 SFP28
(SFP+_RXLOS_P10)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
0
RX_LOSS* P9 SFP28
(SFP+_RXLOS_P6)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
5.12.4.13. Offset 0x0D Module RX_LOSS-3 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
RX_LOSS* P24 SFP28
(SFP+_RXLOS_P23)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
6
RX_LOSS* P23 SFP28
(SFP+_RXLOS_P21)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
5
RX_LOSS* P22 SFP28
(SFP+_RXLOS_P22)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
4
RX_LOSS* P21 SFP28
(SFP+_RXLOS_P18)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
3
RX_LOSS* P20 SFP28
(SFP+_RXLOS_P24)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
2
RX_LOSS* P19 SFP28
(SFP+_RXLOS_P17)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
1
RX_LOSS* P18 SFP28
(SFP+_RXLOS_P13)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
0
RX_LOSS* P17 SFP28
R
1
1: transceiver Loss (Default)
