EDGECORE NETWORKS CORPORATION 2018
124
(SFP+_RXLOS_P19)
0: transceiver is working well
5.12.4.14. Offset 0x0E Module RX_LOSS-4 (Read Only)
Bit
Name
R/W
Reset Value
Description
7:6
Reserved
NA
NA
5
RX_LOSS* P30 SFP28
(SFP+_RXLOS_P25)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
4
RX_LOSS* P29 SFP28
(SFP+_RXLOS_P31)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
3
RX_LOSS* P28 SFP28
(SFP+_RXLOS_P32)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
2
RX_LOSS* P27 SFP28
(SFP+_RXLOS_P28)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
1
RX_LOSS* P26 SFP28
(SFP+_RXLOS_P26)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
0
RX_LOSS* P25 SFP28
(SFP+_RXLOS_P27)
R
1
1: transceiver Loss (Default)
0: transceiver is working well
5.12.4.15. Offset 0x0F Module Present-1 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Present* P8 SFP28
(SFP+_MOD_ABS_P12)
R
1
1: No transceiver(Default)
0: transceiver had plugged
6
Present* P7 SFP28
(SFP+_MOD_ABS_P5)
R
1
1: No transceiver(Default)
0: transceiver had plugged
5
Present* P6 SFP28
(SFP+_MOD_ABS_P1)
R
1
1: No transceiver(Default)
0: transceiver had plugged
4
Present* P5 SFP28
(SFP+_MOD_ABS_P7)
R
1
1: No transceiver(Default)
0: transceiver had plugged
3
Present* P4 SFP28
(SFP+_MOD_ABS_P8)
R
1
1: No transceiver(Default)
0: transceiver had plugged
2
Present* P3 SFP28
(SFP+_MOD_ABS_P4)
R
1
1: No transceiver(Default)
0: transceiver had plugged
1
Present* P2 SFP28
(SFP+_MOD_ABS_P2)
R
1
1:No transceiver(Default)
0: transceiver had plugged
0
Present* P1 SFP28
(SFP+_MOD_ABS_P3)
R
1
1: No transceiver(Default)
0: transceiver had plugged
