Edge-Core AS7326-56X - Page 125

EDGECORE NETWORKS CORPORATION 2018
125
5.12.4.16. Offset 0x10 Module Present-2 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Present* P16 SFP28
(SFP+_MOD_ABS_P20)
R
1
1: No transceiver(Default)
0: transceiver had plugged
6
Present* P15 SFP28
(SFP+_MOD_ABS_P16)
R
1
1: No transceiver(Default)
0: transceiver had plugged
5
Present* P14 SFP28
(SFP+_MOD_ABS_P14)
R
1
1: No transceiver(Default)
0: transceiver had plugged
4
Present* P13 SFP28
(SFP+_MOD_ABS_P15)
R
1
1: No transceiver(Default)
0: transceiver had plugged
3
Present* P12 SFP28
(SFP+_MOD_ABS_P11)
R
1
1: No transceiver(Default)
0: transceiver had plugged
2
Present* P11 SFP28
(SFP+_MOD_ABS_P9)
R
1
1: No transceiver(Default)
0: transceiver had plugged
1
Present* P10 SFP28
(SFP+_MOD_ABS_P10)
R
1
1:No transceiver(Default)
0: transceiver had plugged
0
Present* P9 SFP28
(SFP+_MOD_ABS_P6)
R
1
1: No transceiver(Default)
0: transceiver had plugged
5.12.4.17. Offset 0x11 Module Present-3 (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Present* P24 SFP28
(SFP+_MOD_ABS_P23)
R
1
1: No transceiver(Default)
0: transceiver had plugged
6
Present* P23 SFP28
(SFP+_MOD_ABS_P21)
R
1
1: No transceiver(Default)
0: transceiver had plugged
5
Present* P22 SFP28
(SFP+_MOD_ABS_P22)
R
1
1: No transceiver(Default)
0: transceiver had plugged
4
Present* P21 SFP28
(SFP+_MOD_ABS_P18)
R
1
1: No transceiver(Default)
0: transceiver had plugged
3
Present* P20 SFP28
(SFP+_MOD_ABS_P24)
R
1
1: No transceiver(Default)
0: transceiver had plugged
2
Present* P19 SFP28
(SFP+_MOD_ABS_P17)
R
1
1: No transceiver(Default)
0: transceiver had plugged
1
Present* P18 SFP28
(SFP+_MOD_ABS_P13)
R
1
1:No transceiver(Default)
0: transceiver had plugged
