EDGECORE NETWORKS CORPORATION 2018
126
0
Present* P17 SFP28
(SFP+_MOD_ABS_P19)
R
1
1: No transceiver(Default)
0: transceiver had plugged
5.12.4.18. Offset 0x12 Module Present-4 (Read Only)
Bit
Name
R/W
Reset Value
Description
7:6
Reserved
NA
NA
5
Present* P30 SFP28
(SFP+_MOD_ABS_P25)
R
1
1: No transceiver(Default)
0: transceiver had plugged
4
Present* P29 SFP28
(SFP+_MOD_ABS_P31)
R
1
1: No transceiver(Default)
0: transceiver had plugged
3
Present* P28 SFP28
(SFP+_MOD_ABS_P32)
R
1
1: No transceiver(Default)
0: transceiver had plugged
2
Present* P27 SFP28
(SFP+_MOD_ABS_P28)
R
1
1: No transceiver(Default)
0: transceiver had plugged
1
Present* P26 SFP28
(SFP+_MOD_ABS_P26)
R
1
1:No transceiver(Default)
0: transceiver had plugged
0
Present* P25 SFP28
(SFP+_MOD_ABS_P27)
R
1
1: No transceiver(Default)
0: transceiver had plugged
5.12.4.19. Offset 0x20 SFP28 RGB LED -1 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port1_Active_B
(P3_Lane2_LED_B)
R/W
0
1: Port1_B Active ON
0: Port1_B Active OFF (Default)
4
Port1_Active_G
(P3_Lane2_LED_G)
R/W
0
1: Port1_G Active ON
0: Port1_G Active OFF (Default)
3
Port1_Active_R
(P3_Lane2_LED_R)
R/W
0
1: Port1_R Active ON
0: Port1_R Active OFF (Default)
2
Port1_B
(P3_Lane2_LED_B)
R/W
1
1: Port1_B LED OFF (Default)
0: Port1_B LED ON
1
Port1_G
(P3_Lane2_LED_G)
R/W
1
1: Port1_G LED OFF (Default)
0: Port1_G LED ON
0
Port1_R
(P3_Lane2_LED_R)
R/W
1
1: Port1_R LED OFF (Default)
0: Port1_R LED ON
5.12.4.20. Offset 0x21 SFP28 RGB LED -2 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port2_Active_B
(P2_Lane1_LED_B)
R/W
0
1: Port2_B Active ON
