127
0: Port2_B Active OFF (Default)
4
Port2_Active_G
(P2_Lane1_LED_G)
R/W
0
1: Port2_G Active ON
0: Port2_G Active OFF (Default)
3
Port2_Active_R
(P2_Lane1_LED_R)
R/W
0
1: Port2_R Active ON
0: Port2_R Active OFF (Default)
2
Port2_B
(P2_Lane1_LED_B)
R/W
1
1: Port2_B LED OFF (Default)
0: Port2_B LED ON
1
Port2_G
(P2_Lane1_LED_G)
R/W
1
1: Port2_G LED OFF (Default)
0: Port2_G LED ON
0
Port2_R
(P2_Lane1_LED_R)
R/W
1
1: Port2_R LED OFF (Default)
0: Port2_R LED ON
5.12.4.21. Offset 0x22 SFP28 RGB LED -3 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port3_Active_B
(P4_Lane3_LED_B)
R/W
0
1: Port3_B Active ON
0: Port3_B Active OFF (Default)
4
Port3_Active_G
(P4_Lane3_LED_G)
R/W
0
1: Port3_G Active ON
0: Port3_G Active OFF (Default)
3
Port3_Active_R
(P4_Lane3_LED_R)
R/W
0
1: Port3_R Active ON
0: Port3_R Active OFF (Default)
2
Port3_B
(P4_Lane3_LED_B)
R/W
1
1: Port3_B LED OFF (Default)
0: Port3_B LED ON
1
Port3_G
(P4_Lane3_LED_G)
R/W
1
1: Port3_G LED OFF (Default)
0: Port3_G LED ON
0
Port3_R
(P4_Lane3_LED_R)
R/W
1
1: Port3_R LED OFF (Default)
0: Port3_R LED ON
5.12.4.22. Offset 0x23 SFP28 RGB LED -4 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port4_Active_B
(P8_Lane3_LED_B)
R/W
0
1: Port4_B Active ON
0: Port4_B Active OFF (Default)
4
Port4_Active_G
(P8_Lane3_LED_G)
R/W
0
1: Port4_G Active ON
0: Port4_G Active OFF (Default)
3
Port4_Active_R
(P8_Lane3_LED_R)
R/W
0
1: Port4_R Active ON
0: Port4_R Active OFF (Default)
2
Port4_B
(P8_Lane3_LED_B)
R/W
1
1: Port4_B LED OFF (Default)
0: Port4_B LED ON
1
Port4_G
(P8_Lane3_LED_G)
R/W
1
1: Port4_G LED OFF (Default)
0: Port4_G LED ON
