Edge-Core AS7326-56X - Page 128

EDGECORE NETWORKS CORPORATION 2018
128
0
Port4_R
(P8_Lane3_LED_R)
R/W
1
1: Port4_R LED OFF (Default)
0: Port4_R LED ON
5.12.4.23. Offset 0x24 SFP28 RGB LED -5 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port5_Active_B
(P7_Lane2_LED_B)
R/W
0
1: Port5_B Active ON
0: Port5_B Active OFF (Default)
4
Port5_Active_G
(P7_Lane2_LED_G)
R/W
0
1: Port5_G Active ON
0: Port5_G Active OFF (Default)
3
Port5_Active_R
(P7_Lane2_LED_R)
R/W
0
1: Port5_R Active ON
0: Port5_R Active OFF (Default)
2
Port5_R
(P7_Lane2_LED_B)
R/W
1
1: Port5_B LED OFF (Default)
0: Port5_B LED ON
1
Port5_R
(P7_Lane2_LED_G)
R/W
1
1: Port5_G LED OFF (Default)
0: Port5_G LED ON
0
Port5_R
(P7_Lane2_LED_R)
R/W
1
1: Port5_R LED OFF (Default)
0: Port5_R LED ON
5.12.4.24. Offset 0x25 SFP28 RGB LED -6 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port6_Active_B
(P1_Lane0_LED_B)
R/W
0
1: Port6_B Active ON
0: Port6_B Active OFF (Default)
4
Port6_Active_G
(P1_Lane0_LED_G)
R/W
0
1: Port6_G Active ON
0: Port6_G Active OFF (Default)
3
Port6_Active_R
(P1_Lane0_LED_R)
R/W
0
1: Port6_R Active ON
0: Port6_R Active OFF (Default)
2
Port6_B
(P1_Lane0_LED_B)
R/W
1
1: Port6_B LED OFF (Default)
0: Port6_B LED ON
1
Port6_G
(P1_Lane0_LED_G)
R/W
1
1: Port6_G LED OFF (Default)
0: Port6_G LED ON
0
Port6_R
(P1_Lane0_LED_R)
R/W
1
1: Port6_R LED OFF (Default)
0: Port6_R LED ON
5.12.4.25. Offset 0x26 SFP28 RGB LED -7 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port7_Active_B
(P5_Lane0_LED_B)
R/W
0
1: Port7_B Active ON
0: Port7_B Active OFF (Default)
4
Port7_Active_G
(P5_Lane0_LED_G)
R/W
0
1: Port7_G Active ON
0: Port7_G Active OFF (Default)
