Edge-Core AS7326-56X - Page 131

EDGECORE NETWORKS CORPORATION 2018
131
(P11_Lane2_LED_B)
0: Port12_B LED ON
1
Port12_G
(P11_Lane2_LED_G)
R/W
1
1: Port12_G LED OFF (Default)
0: Port12_G LED ON
0
Port12_R
(P11_Lane2_LED_R)
R/W
1
1: Port12_R LED OFF (Default)
0: Port12_R LED ON
5.12.4.31. Offset 0x2C SFP28 RGB LED -13 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port13_Active_B
(P15_Lane2_LED_B)
R/W
0
1: Port13_B Active ON
0: Port13_B Active OFF (Default)
4
Port13_Active_G
(P15_Lane2_LED_G)
R/W
0
1: Port13_G Active ON
0: Port13_G Active OFF (Default)
3
Port13_Active_R
(P15_Lane2_LED_R)
R/W
0
1: Port13_R Active ON
0: Port13_R Active OFF (Default)
2
Port13_B
(P15_Lane2_LED_B)
R/W
1
1: Port13_B LED OFF (Default)
0: Port13_B LED ON
1
Port13_G
(P15_Lane2_LED_G)
R/W
1
1: Port13_G LED OFF (Default)
0: Port13_G LED ON
0
Port13_R
(P15_Lane2_LED_R)
R/W
1
1: Port13_R LED OFF (Default)
0: Port13_R LED ON
5.12.4.32. Offset 0x2D SFP28 RGB LED -14 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port14_Active_B
(P14_Lane1_LED_B)
R/W
0
1: Port14_B Active ON
0: Port14_B Active OFF (Default)
4
Port14_Active_G
(P14_Lane1_LED_G)
R/W
0
1: Port14_G Active ON
0: Port14_G Active OFF (Default)
3
Port14_Active_R
(P14_Lane1_LED_R)
R/W
0
1: Port14_R Active ON
0: Port14_R Active OFF (Default)
2
Port14_B
(P14_Lane1_LED_B)
R/W
1
1: Port14_B LED OFF (Default)
0: Port14_B LED ON
1
Port14_G
(P14_Lane1_LED_G)
R/W
1
1: Port14_G LED OFF (Default)
0: Port14_G LED ON
0
Port14_R
(P14_Lane1_LED_R)
R/W
1
1: Port14_R LED OFF (Default)
0: Port14_R LED ON
5.12.4.33. Offset 0x2E SFP28 RGB LED -15 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port15_Active_B
R/W
0
1: Port15_B Active ON
