5.12.4.28. Offset 0x29 SFP28 RGB LED -10 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port10_Active_B
(P10_Lane1_LED_B)
R/W
0
1: Port10_B Active ON
0: Port10_B Active OFF (Default)
4
Port10_Active_G
(P10_Lane1_LED_G)
R/W
0
1: Port10_G Active ON
0: Port10_G Active OFF (Default)
3
Port10_Active_R
(P10_Lane1_LED_R)
R/W
0
1: Port10_R Active ON
0: Port10_R Active OFF (Default)
2
Port10_B
(P10_Lane1_LED_B)
R/W
1
1: Port10_B LED OFF (Default)
0: Port10_B LED ON
1
Port10_G
(P10_Lane1_LED_G)
R/W
1
1: Port10_G LED OFF (Default)
0: Port10_G LED ON
0
Port10_R
(P10_Lane1_LED_R)
R/W
1
1: Port10_R LED OFF (Default)
0: Port10_R LED ON
5.12.4.29. Offset 0x2A SFP28 RGB LED -11 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port11_Active_B
(P9_Lane0_LED_B)
R/W
0
1: Port11_B Active ON
0: Port11_B Active OFF (Default)
4
Port11_Active_G
(P9_Lane0_LED_G)
R/W
0
1: Port11_G Active ON
0: Port11_G Active OFF (Default)
3
Port11_Active_R
(P9_Lane0_LED_R)
R/W
0
1: Port11_R Active ON
0: Port11_R Active OFF (Default)
2
Port11_B
(P9_Lane0_LED_B)
R/W
1
1: Port11_B LED OFF (Default)
0: Port11_B LED ON
1
Port11_G
(P9_Lane0_LED_G)
R/W
1
1: Port11_G LED OFF (Default)
0: Port11_G LED ON
0
Port11_R
(P9_Lane0_LED_R)
R/W
1
1: Port11_R LED OFF (Default)
0: Port11_R LED ON
5.12.4.30. Offset 0x2B SFP28 RGB LED -12 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port12_Active_B
(P11_Lane2_LED_B)
R/W
0
1: Port12_B Active ON
0: Port12_B Active OFF (Default)
4
Port12_Active_G
(P11_Lane2_LED_G)
R/W
0
1: Port12_G Active ON
0: Port12_G Active OFF (Default)
3
Port12_Active_R
(P11_Lane2_LED_R)
R/W
0
1: Port12_R Active ON
0: Port12_R Active OFF (Default)
2
Port12_B
R/W
1
1: Port12_B LED OFF (Default)
