Edge-Core AS7326-56X - Page 134

EDGECORE NETWORKS CORPORATION 2018
134
3
Port20_Active_R
(P24_Lane3_LED_R)
R/W
0
1: Port20_R Active ON
0: Port20_R Active OFF (Default)
2
Port20_B
(P24_Lane3_LED_B)
R/W
1
1: Port20_B LED OFF (Default)
0: Port20_B LED ON
1
Port20_G
(P24_Lane3_LED_G)
R/W
1
1: Port20_G LED OFF (Default)
0: Port20_G LED ON
0
Port20_R
(P24_Lane3_LED_R)
R/W
1
1: Port20_R LED OFF (Default)
0: Port20_R LED ON
5.12.4.39. Offset 0x34 SFP28 RGB LED -21 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port21_Active_B
(P18_Lane1_LED_B)
R/W
0
1: Port21_B Active ON
0: Port21_B Active OFF (Default)
4
Port21_Active_G
(P18_Lane1_LED_G)
R/W
0
1: Port21_G Active ON
0: Port21_G Active OFF (Default)
3
Port21_Active_R
(P18_Lane1_LED_R)
R/W
0
1: Port21_R Active ON
0: Port21_R Active OFF (Default)
2
Port21_B
(P18_Lane1_LED_B)
R/W
1
1: Port21_B LED OFF (Default)
0: Port21_B LED ON
1
Port21_G
(P18_Lane1_LED_G)
R/W
1
1: Port21_G LED OFF (Default)
0: Port21_G LED ON
0
Port21_R
(P18_Lane1_LED_R)
R/W
1
1: Port21_R LED OFF (Default)
0: Port21_R LED ON
5.12.4.40. Offset 0x35 SFP28 RGB LED -22 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port22_Active_B
(P22_Lane1_LED_B)
R/W
0
1: Port22_B Active ON
0: Port22_B Active OFF (Default)
4
Port22_Active_G
(P22_Lane1_LED_G)
R/W
0
1: Port22_G Active ON
0: Port22_G Active OFF (Default)
3
Port22_Active_R
(P22_Lane1_LED_R)
R/W
0
1: Port22_R Active ON
0: Port22_R Active OFF (Default)
2
Port22_B
(P22_Lane1_LED_B)
R/W
1
1: Port22_B LED OFF (Default)
0: Port22_B LED ON
1
Port22_G
(P22_Lane1_LED_G)
R/W
1
1: Port22_G LED OFF (Default)
0: Port22_G LED ON
0
Port22_R
(P22_Lane1_LED_R)
R/W
1
1: Port22_R LED OFF (Default)
0: Port22_R LED ON
