Edge-Core AS7326-56X - Page 135

EDGECORE NETWORKS CORPORATION 2018
135
5.12.4.41. Offset 0x36 SFP28 RGB LED -23 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port23_Active_B
(P21_Lane0_LED_B)
R/W
0
1: Port23_B Active ON
0: Port23_B Active OFF (Default)
4
Port23_Active_G
(P21_Lane0_LED_G)
R/W
0
1: Port23_G Active ON
0: Port23_G Active OFF (Default)
3
Port23_Active_R
(P21_Lane0_LED_R)
R/W
0
1: Port23_R Active ON
0: Port23_R Active OFF (Default)
2
Port23_B
(P21_Lane0_LED_B)
R/W
1
1: Port23_B LED OFF (Default)
0: Port23_B LED ON
1
Port23_G
(P21_Lane0_LED_G)
R/W
1
1: Port23_G LED OFF (Default)
0: Port23_G LED ON
0
Port23_R
(P21_Lane0_LED_R)
R/W
1
1: Port23_R LED OFF (Default)
0: Port23_R LED ON
5.12.4.42. Offset 0x37 SFP28 RGB LED -24 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port24_Active_B
(P23_Lane2_LED_B)
R/W
0
1: Port24_B Active ON
0: Port24_B Active OFF (Default)
4
Port24_Active_G
(P23_Lane2_LED_G)
R/W
0
1: Port24_G Active ON
0: Port24_G Active OFF (Default)
3
Port24_Active_R
(P23_Lane2_LED_R)
R/W
0
1: Port24_R Active ON
0: Port24_R Active OFF (Default)
2
Port24_B
(P23_Lane2_LED_B)
R/W
1
1: Port24_B LED OFF (Default)
0: Port24_B LED ON
1
Port24_G
(P23_Lane2_LED_G)
R/W
1
1: Port24_G LED OFF (Default)
0: Port24_G LED ON
0
Port24_R
(P23_Lane2_LED_R)
R/W
1
1: Port24_R LED OFF (Default)
0: Port24_R LED ON
5.12.4.43. Offset 0x38 SFP28 RGB LED -25 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port25_Active_B
(P27_Lane2_LED_B)
R/W
0
1: Port25_B Active ON
0: Port25_B Active OFF (Default)
4
Port25_Active_G
(P27_Lane2_LED_G)
R/W
0
1: Port25_G Active ON
0: Port25_G Active OFF (Default)
3
Port25_Active_R
(P27_Lane2_LED_R)
R/W
0
1: Port25_R Active ON
0: Port25_R Active OFF (Default)
2
Port25_B
R/W
1
1: Port25_B LED OFF (Default)
