(P27_Lane2_LED_B)
0: Port25_B LED ON
1
Port25_G
(P27_Lane2_LED_G)
R/W
1
1: Port25_G LED OFF (Default)
0: Port25_G LED ON
0
Port25_R
(P27_Lane2_LED_R)
R/W
1
1: Port25_R LED OFF (Default)
0: Port25_R LED ON
5.12.4.44. Offset 0x39 SFP28 RGB LED -26 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port26_Active_B
(P26_Lane1_LED_B)
R/W
0
1: Port26_B Active ON
0: Port26_B Active OFF (Default)
4
Port26_Active_G
(P26_Lane1_LED_G)
R/W
0
1: Port26_G Active ON
0: Port26_G Active OFF (Default)
3
Port26_Active_R
(P26_Lane1_LED_R)
R/W
0
1: Port26_R Active ON
0: Port26_R Active OFF (Default)
2
Port26_B
(P26_Lane1_LED_B)
R/W
1
1: Port26_B LED OFF (Default)
0: Port26_B LED ON
1
Port26_G
(P26_Lane1_LED_G)
R/W
1
1: Port26_G LED OFF (Default)
0: Port26_G LED ON
0
Port26_R
(P26_Lane1_LED_R)
R/W
1
1: Port26_R LED OFF (Default)
0: Port26_R LED ON
5.12.4.45. Offset 0x3A SFP28 RGB LED -27 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port27_Active_B
(P28_Lane3_LED_B)
R/W
0
1: Port27_B Active ON
0: Port27_B Active OFF (Default)
4
Port27_Active_G
(P28_Lane3_LED_G)
R/W
0
1: Port27_G Active ON
0: Port27_G Active OFF (Default)
3
Port27_Active_R
(P28_Lane3_LED_R)
R/W
0
1: Port27_R Active ON
0: Port27_R Active OFF (Default)
2
Port27_B
(P28_Lane3_LED_B)
R/W
1
1: Port27_B LED OFF (Default)
0: Port27_B LED ON
1
Port27_G
(P28_Lane3_LED_G)
R/W
1
1: Port27_G LED OFF (Default)
0: Port27_G LED ON
0
Port27_R
(P28_Lane3_LED_R)
R/W
1
1: Port27_R LED OFF (Default)
0: Port27_R LED ON
5.12.4.46. Offset 0x3B SFP28 RGB LED -28 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port28_Active_B
R/W
0
1: Port28_B Active ON
