(P32_Lane3_LED_B)
0: Port28_B Active OFF (Default)
4
Port28_Active_G
(P32_Lane3_LED_G)
R/W
0
1: Port28_G Active ON
0: Port28_G Active OFF (Default)
3
Port28_Active_R
(P32_Lane3_LED_R)
R/W
0
1: Port28_R Active ON
0: Port28_R Active OFF (Default)
2
Port28_B
(P32_Lane3_LED_B)
R/W
1
1: Port28_B LED OFF (Default)
0: Port28_B LED ON
1
Port28_G
(P32_Lane3_LED_G)
R/W
1
1: Port28_G LED OFF (Default)
0: Port28_G LED ON
0
Port28_R
(P32_Lane3_LED_R)
R/W
1
1: Port28_R LED OFF (Default)
0: Port28_R LED ON
5.12.4.47. Offset 0x3C SFP28 RGB LED -29 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port29_Active_B
(P31_Lane2_LED_B)
R/W
0
1: Port29_B Active ON
0: Port29_B Active OFF (Default)
4
Port29_Active_G
(P31_Lane2_LED_G)
R/W
0
1: Port29_G Active ON
0: Port29_G Active OFF (Default)
3
Port29_Active_R
(P31_Lane2_LED_R)
R/W
0
1: Port29_R Active ON
0: Port29_R Active OFF (Default)
2
Port29_B
(P31_Lane2_LED_B)
R/W
1
1: Port29_B LED OFF (Default)
0: Port29_B LED ON
1
Port29_G
(P31_Lane2_LED_G)
R/W
1
1: Port29_G LED OFF (Default)
0: Port29_G LED ON
0
Port29_R
(P31_Lane2_LED_R)
R/W
1
1: Port29_R LED OFF (Default)
0: Port29_R LED ON
5.12.4.48. Offset 0x3D SFP28 RGB LED -30 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port30_Active_B
(P25_Lane0_LED_B)
R/W
0
1: Port30_B Active ON
0: Port30_B Active OFF (Default)
4
Port30_Active_G
(P25_Lane0_LED_G)
R/W
0
1: Port30_G Active ON
0: Port30_G Active OFF (Default)
3
Port30_Active_R
(P25_Lane0_LED_R)
R/W
0
1: Port30_R Active ON
0: Port30_R Active OFF (Default)
2
Port30_B
(P25_Lane0_LED_B)
R/W
1
1: Port30_B LED OFF (Default)
0: Port30_B LED ON
1
Port30_G
(P25_Lane0_LED_G)
R/W
1
1: Port30_G LED OFF (Default)
0: Port30_G LED ON
