Edge-Core AS7326-56X - Page 138

EDGECORE NETWORKS CORPORATION 2018
138
0
Port30_R
(P25_Lane0_LED_R)
R/W
1
1: Port30_R LED OFF (Default)
0: Port30_R LED ON
5.12.4.49. Offset 0x3E SFP28 RGB LED -31 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port31_Active_B
(P29_Lane0_LED_B)
R/W
0
1: Port31_B Active ON
0: Port31_B Active OFF (Default)
4
Port31_Active_G
(P29_Lane0_LED_G)
R/W
0
1: Port31_G Active ON
0: Port31_G Active OFF (Default)
3
Port31_Active_R
(P29_Lane0_LED_R)
R/W
0
1: Port31_R Active ON
0: Port31_R Active OFF (Default)
2
Port31_B
(P29_Lane0_LED_B)
R/W
1
1: Port31_B LED OFF (Default)
0: Port31_B LED ON
1
Port31_G
(P29_Lane0_LED_G)
R/W
1
1: Port31_G LED OFF (Default)
0: Port31_G LED ON
0
Port31_R
(P29_Lane0_LED_R)
R/W
1
1: Port31_R LED OFF (Default)
0: Port31_R LED ON
5.12.4.50. Offset 0x3F SFP28 RGB LED -32 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port32_Active_B
(P36_Lane3_LED_R)
R/W
0
1: Port32_B Active ON
0: Port32_B Active OFF (Default)
4
Port32_Active_G
(P36_Lane3_LED_G)
R/W
0
1: Port32_G Active ON
0: Port32_G Active OFF (Default)
3
Port32_Active_R
(P36_Lane3_LED_R)
R/W
0
1: Port32_R Active ON
0: Port32_R Active OFF (Default)
2
Port32_B
(P36_Lane3_LED_B)
R/W
1
1: Port32_B LED OFF (Default)
0: Port32_B LED ON
1
Port32_G
(P36_Lane3_LED_G)
R/W
1
1: Port32_G LED OFF (Default)
0: Port32_G LED ON
0
Port32_R
(P36_Lane3_LED_R)
R/W
1
1: Port32_R LED OFF (Default)
0: Port32_R LED ON
5.12.4.51. Offset 0x40 SFP28 RGB LED -33 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port33_Active_B
(P30_Lane1_LED_B)
R/W
0
1: Port33_B Active ON
0: Port33_B Active OFF (Default)
4
Port33_Active_G
(P30_Lane1_LED_G)
R/W
0
1: Port33_G Active ON
0: Port33_G Active OFF (Default)
