Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
144
R13
P55_Lane1_LED_R
OUT
M13
N/A
P12
P55_Lane3_LED_G
OUT
P13
SFP_FX0_LED_B
OUT
P11
P56_Lane2_LED_G
OUT
R16
P56_Lane2_LED_R
OUT
M11
SFP_FX1_LED_G
OUT
E10
CPLD3_INT
OUT
R3
P53_Lane1_LED_R
OUT
R4
P54_Lane1_LED_R
OUT
N13
SFP_FX0_LED_R
OUT
K14
N/A
P14
MGMT_LINK_R
OUT
E13
N/A
D12
P47_Lane2_LED_G
OUT
E14
N/A
P2
P52_Lane3_LED_R
OUT
L15
N/A
M12
MGMT_ACT
OUT
B16
N/A
M16
N/A
J14
N/A
P9
P55_Lane0_LED_R
OUT
M7
PHY_LED2_CPLD
IN
M6
PHY_LED1_CPLD
IN
N6
P54_Lane3_LED_G
OUT
P7
P53_Lane3_LED_G
OUT
P5
P53_Lane2_LED_G
OUT
P15
P55_Lane3_LED_R
OUT
H16
N/A
J16
N/A
N15
P56_Lane3_LED_G
OUT
M15
N/A
L16
N/A
J12
N/A
N9
P55_Lane1_LED_B
OUT
N16
P56_Lane3_LED_B
OUT
