Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
145
N7
P54_Lane3_LED_R
OUT
N8
P56_Lane0_LED_R
OUT
P8
P53_Lane3_LED_R
OUT
J15
N/A
H15
N/A
P10
P55_Lane2_LED_R
OUT
R8
P53_Lane2_LED_B
OUT
L5
P55_Lane0_LED_B
OUT
R12
P56_Lane1_LED_R
OUT
J4
P51_Lane2_LED_B
OUT
L2
P52_Lane1_LED_G
OUT
N1
P52_Lane2_LED_G
OUT
J2
P51_Lane0_LED_G
OUT
J1
P50_Lane3_LED_R
OUT
H2
P50_Lane3_LED_B
OUT
K3
P52_Lane2_LED_B
OUT
G1
P49_Lane3_LED_G
OUT
M2
P51_Lane2_LED_G
OUT
K5
P54_Lane0_LED_R
OUT
P4
P54_Lane2_LED_B
OUT
T12
P56_Lane1_LED_B
OUT
G4
IP_LED_CLK3
IN
N3
P53_Lane0_LED_B
OUT
T8
P54_Lane2_LED_G
OUT
K1
P52_Lane0_LED_G
OUT
K2
P51_Lane0_LED_R
OUT
R6
P53_Lane1_LED_G
OUT
K4
P52_Lane2_LED_R
OUT
M1
P51_Lane1_LED_R
OUT
R1
P51_Lane3_LED_B
OUT
F1
N/A
OUT
G2
P50_Lane3_LED_G
OUT
L1
P51_Lane1_LED_B
OUT
E3
IP_LED_DATA2
IN
C5
P34_Lane1_LED_R
OUT
C6
P41_Lane0_LED_R
OUT
A4
P33_Lane0_LED_B
OUT
