Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
152
5
Port47_Active_B
(P48_Lane3_LED_B)
R/W
0
1: Port47_B Active ON
0: Port47_B Active OFF (Default)
4
Port47_Active_G
(P48_Lane3_LED_G)
R/W
0
1: Port47_G Active ON
0: Port47_G Active OFF (Default)
3
Port47_Active_R
(P48_Lane3_LED_R)
R/W
0
1: Port47_R Active ON
0: Port47_R Active OFF (Default)
2
Port47_B
(P48_Lane3_LED_B)
R/W
1
1: Port47_B LED OFF (Default)
0: Port47_B LED ON
1
Port47_G
(P48_Lane3_LED_G)
R/W
1
1: Port47_G LED OFF (Default)
0: Port47_G LED ON
0
Port47_R
(P48_Lane3_LED_R)
R/W
1
1: Port47_R LED OFF (Default)
0: Port47_R LED ON
5.12.6.13. Offset 0x30 QSFP28 RGB LED -1 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port49_LED1_Active_B
(P49_Lane3_LED_B)
R/W
0
1: Port49_LED1_B Active ON
0: Port49_LED1_B Active OFF (Default)
4
Port49_LED1_Active_G
(P49_Lane3_LED_G)
R/W
0
1: Port49_LED1_G Active ON
0: Port49_LED1_G Active OFF (Default)
3
Port49_LED1_Active_R
(P49_Lane3_LED_R)
R/W
0
1: Port49_LED1_R Active ON
0: Port49_LED1_R Active OFF (Default)
2
Port49_LED1_B
(P49_Lane3_LED_B)
R/W
1
1: Port49_LED1_B LED OFF (Default)
0: Port49_LED1_B LED ON
1
Port49_LED1_G
(P49_Lane3_LED_G)
R/W
1
1: Port49_LED1_G LED OFF (Default)
0: Port49_LED1_G LED ON
0
Port49_LED1_R
(P49_Lane3_LED_R)
R/W
1
1: Port49_LED1_R LED OFF (Default)
0: Port49_LED1_R LED ON
5.12.6.14. Offset 0x31 QSFP28 RGB LED -2 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port49_LED2_Active_B
(P49_Lane2_LED_B)
R/W
0
1: Port49_LED2_B Active ON
0: Port49_LED2_B Active OFF (Default)
4
Port49_LED2_Active_G
(P49_Lane2_LED_G)
R/W
0
1: Port49_LED2_G Active ON
0: Port49_LED2_G Active OFF (Default)
3
Port49_LED2_Active_R
(P49_Lane2_LED_R)
R/W
0
1: Port49_LED2_R Active ON
0: Port49_LED2_R Active OFF (Default)
2
Port49_LED2_B
(P49_Lane2_LED_B)
R/W
1
1: Port49_LED2_B LED OFF (Default)
0: Port49_LED2_B LED ON
