Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
151
(P44_Lane3_LED_B)
0: Port43_B LED ON
1
Port43_G
(P44_Lane3_LED_G)
R/W
1
1: Port43_G LED OFF (Default)
0: Port43_G LED ON
0
Port43_R
(P44_Lane3_LED_R)
R/W
1
1: Port43_R LED OFF (Default)
0: Port43_R LED ON
5.12.6.10. Offset 0x17 SFP28 RGB LED -8 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port44_Active_B
(P45_Lane0_LED_B)
R/W
0
1: Port44_B Active ON
0: Port44_B Active OFF (Default)
4
Port44_Active_G
(P45_Lane0_LED_G)
R/W
0
1: Port44_G Active ON
0: Port44_G Active OFF (Default)
3
Port44_Active_R
(P45_Lane0_LED_R)
R/W
0
1: Port44_R Active ON
0: Port44_R Active OFF (Default)
2
Port44_B
(P45_Lane0_LED_B)
R/W
1
1: Port44_B LED OFF (Default)
0: Port44_B LED ON
1
Port44_G
(P45_Lane0_LED_G)
R/W
1
1: Port44_G LED OFF (Default)
0: Port44_G LED ON
0
Port44_R
(P45_Lane0_LED_R)
R/W
1
1: Port44_R LED OFF (Default)
0: Port44_R LED ON
5.12.6.11. Offset 0x18 SFP28 RGB LED -9 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port46_Active_B
(P47_Lane2_LED_B)
R/W
0
1: Port46_B Active ON
0: Port46_B Active OFF (Default)
4
Port46_Active_G
(P47_Lane2_LED_G)
R/W
0
1: Port46_G Active ON
0: Port46_G Active OFF (Default)
3
Port46_Active_R
(P47_Lane2_LED_R)
R/W
0
1: Port46_R Active ON
0: Port46_R Active OFF (Default)
2
Port46_B
(P47_Lane2_LED_B)
R/W
1
1: Port46_B LED OFF (Default)
0: Port46_B LED ON
1
Port46_G
(P47_Lane2_LED_G)
R/W
1
1: Port46_G LED OFF (Default)
0: Port46_G LED ON
0
Port46_R
(P47_Lane2_LED_R)
R/W
1
1: Port46_R LED OFF (Default)
0: Port46_R LED ON
5.12.6.12. Offset 0x19 SFP28 RGB LED -10 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
