5.12.6.7. Offset 0x14 SFP28 RGB LED -5 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port40_Active_B
(P41_Lane0_LED_B)
R/W
0
1: Port40_B Active ON
0: Port40_B Active OFF (Default)
4
Port40_Active_G
(P41_Lane0_LED_G)
R/W
0
1: Port40_G Active ON
0: Port40_G Active OFF (Default)
3
Port40_Active_R
(P41_Lane0_LED_R)
R/W
0
1: Port40_R Active ON
0: Port40_R Active OFF (Default)
2
Port40_B
(P41_Lane0_LED_B)
R/W
1
1: Port40_B LED OFF (Default)
0: Port40_B LED ON
1
Port40_G
(P41_Lane0_LED_G)
R/W
1
1: Port40_G LED OFF (Default)
0: Port40_G LED ON
0
Port40_R
(P41_Lane0_LED_R)
R/W
1
1: Port40_R LED OFF (Default)
0: Port40_R LED ON
5.12.6.8. Offset 0x15 SFP28 RGB LED -6 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port41_Active_B
(P42_Lane1_LED_B)
R/W
0
1: Port41_B Active ON
0: Port41_B Active OFF (Default)
4
Port41_Active_G
(P42_Lane1_LED_G)
R/W
0
1: Port41_G Active ON
0: Port41_G Active OFF (Default)
3
Port41_Active_R
(P42_Lane1_LED_R)
R/W
0
1: Port41_R Active ON
0: Port41_R Active OFF (Default)
2
Port41_B
(P42_Lane1_LED_B)
R/W
1
1: Port41_B LED OFF (Default)
0: Port41_B LED ON
1
Port41_G
(P42_Lane1_LED_G)
R/W
1
1: Port41_G LED OFF (Default)
0: Port41_G LED ON
0
Port41_R
(P42_Lane1_LED_R)
R/W
1
1: Port41_R LED OFF (Default)
0: Port41_R LED ON
5.12.6.9. Offset 0x16 SFP28 RGB LED -7 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port43_Active_B
(P44_Lane3_LED_B)
R/W
0
1: Port43_B Active ON
0: Port43_B Active OFF (Default)
4
Port43_Active_G
(P44_Lane3_LED_G)
R/W
0
1: Port43_G Active ON
0: Port43_G Active OFF (Default)
3
Port43_Active_R
(P44_Lane3_LED_R)
R/W
0
1: Port43_R Active ON
0: Port43_R Active OFF (Default)
2
Port43_B
R/W
1
1: Port43_B LED OFF (Default)
