EDGECORE NETWORKS CORPORATION 2018
149
3
Port35_Active_R
(P33_Lane0_LED_R)
R/W
0
1: Port35_R Active ON
0: Port35_R Active OFF (Default)
2
Port35_B
(P33_Lane0_LED_B)
R/W
1
1: Port35_B LED OFF (Default)
0: Port35_B LED ON
1
Port35_G
(P33_Lane0_LED_G)
R/W
1
1: Port35_G LED OFF (Default)
0: Port35_G LED ON
0
Port35_R
(P33_Lane0_LED_R)
R/W
1
1: Port35_R LED OFF (Default)
0: Port35_R LED ON
5.12.6.5. Offset 0x12 SFP28 RGB LED -3 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port37_Active_B
(P38_Lane1_LED_B)
R/W
0
1: Port37_B Active ON
0: Port37_B Active OFF (Default)
4
Port37_Active_G
(P38_Lane1_LED_G)
R/W
0
1: Port37_G Active ON
0: Port37_G Active OFF (Default)
3
Port37_Active_R
(P38_Lane1_LED_R)
R/W
0
1: Port37_R Active ON
0: Port37_R Active OFF (Default)
2
Port37_B
(P38_Lane1_LED_B)
R/W
1
1: Port37_B LED OFF (Default)
0: Port37_B LED ON
1
Port37_G
(P38_Lane1_LED_G)
R/W
1
1: Port37_G LED OFF (Default)
0: Port37_G LED ON
0
Port37_R
(P38_Lane1_LED_R)
R/W
1
1: Port37_R LED OFF (Default)
0: Port37_R LED ON
5.12.6.6. Offset 0x13 SFP28 RGB LED -4 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port38_Active_B
(P39_Lane2_LED_B)
R/W
0
1: Port38_B Active ON
0: Port38_B Active OFF (Default)
4
Port38_Active_G
(P39_Lane2_LED_G)
R/W
0
1: Port38_G Active ON
0: Port38_G Active OFF (Default)
3
Port38_Active_R
(P39_Lane2_LED_R)
R/W
0
1: Port38_R Active ON
0: Port38_R Active OFF (Default)
2
Port38_B
(P39_Lane2_LED_B)
R/W
1
1: Port38_B LED OFF (Default)
0: Port38_B LED ON
1
Port38_G
(P39_Lane2_LED_G)
R/W
1
1: Port38_G LED OFF (Default)
0: Port38_G LED ON
0
Port38_R
(P39_Lane2_LED_R)
R/W
1
1: Port38_R LED OFF (Default)
0: Port38_R LED ON
