Port53_LED4_Active_B
(P53_Lane0_LED_B)
R/W
0
1: Port53_LED4_B Active ON
0: Port53_LED4_B Active OFF (Default)
4
Port53_LED4_Active_G
(P53_Lane0_LED_G)
R/W
0
1: Port53_LED4_G Active ON
0: Port53_LED4_G Active OFF (Default)
3
Port53_LED4_Active_R
(P53_Lane0_LED_R)
R/W
0
1: Port53_LED4_R Active ON
0: Port53_LED4_R Active OFF (Default)
2
Port53_LED4_B
(P53_Lane0_LED_B)
R/W
1
1: Port53_LED4_B LED OFF (Default)
0: Port53_LED4_B LED ON
1
Port53_LED4_G
(P53_Lane0_LED_G)
R/W
1
1: Port53_LED4_G LED OFF (Default)
0: Port53_LED4_G LED ON
0
Port53_LED4_R
(P53_Lane0_LED_R)
R/W
1
1: Port53_LED4_R LED OFF (Default)
0: Port53_LED4_R LED ON
5.12.6.33. Offset 0x44 QSFP28 RGB LED -21 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port54_LED1_Active_B
(P54_Lane0_LED_B)
R/W
0
1: Port54_LED1_B Active ON
0: Port54_LED1_B Active OFF (Default)
4
Port54_LED1_Active_G
(P54_Lane0_LED_G)
R/W
0
1: Port54_LED1_G Active ON
0: Port54_LED1_G Active OFF (Default)
3
Port54_LED1_Active_R
(P54_Lane0_LED_R)
R/W
0
1: Port54_LED1_R Active ON
0: Port54_LED1_R Active OFF (Default)
2
Port54_LED1_B
(P54_Lane0_LED_B)
R/W
1
1: Port54_LED1_B LED OFF (Default)
0: Port54_LED1_B LED ON
1
Port54_LED1_G
(P54_Lane0_LED_G)
R/W
1
1: Port54_LED1_G LED OFF (Default)
0: Port54_LED1_G LED ON
0
Port54_LED1_R
(P54_Lane0_LED_R)
R/W
1
1: Port54_LED1_R LED OFF (Default)
0: Port54_LED1_R LED ON
5.12.6.34. Offset 0x45 QSFP28 RGB LED -22 (Read& Write)
42
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port54_LED2_Active_B
(P54_Lane1_LED_B)
R/W
0
1: Port54_LED2_B Active ON
0: Port54_LED2_B Active OFF (Default)
4
Port54_LED2_Active_G
(P54_Lane1_LED_G)
R/W
0
1: Port54_LED2_G Active ON
0: Port54_LED2_G Active OFF (Default)
3
Port54_LED2_Active_R
(P54_Lane1_LED_R)
R/W
0
1: Port54_LED2_R Active ON
0: Port54_LED2_R Active OFF (Default)
2
Port54_LED2_B
(P54_Lane1_LED_B)
R/W
1
1: Port54_LED2_B LED OFF (Default)
0: Port54_LED2_B LED ON
