Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
162
5
Port55_LED1_Active_B
(P55_Lane0_LED_B)
R/W
0
1: Port55_LED1_B Active ON
0: Port55_LED1_B Active OFF (Default)
4
Port55_LED1_Active_G
(P55_Lane0_LED_G)
R/W
0
1: Port55_LED1_G Active ON
0: Port55_LED1_G Active OFF (Default)
3
Port55_LED1_Active_R
(P55_Lane0_LED_R)
R/W
0
1: Port55_LED1_R Active ON
0: Port55_LED1_R Active OFF (Default)
2
Port55_LED1_B
(P55_Lane0_LED_B)
R/W
1
1: Port55_LED1_B LED OFF (Default)
0: Port55_LED1_B LED ON
1
Port55_LED1_G
(P55_Lane0_LED_G)
R/W
1
1: Port55_LED1_G LED OFF (Default)
0: Port55_LED1_G LED ON
0
Port55_LED1_R
(P55_Lane0_LED_R)
R/W
1
1: Port55_LED1_R LED OFF (Default)
0: Port55_LED1_R LED ON
5.12.6.38. Offset 0x49 QSFP28 RGB LED -26 (Read& Write)
42
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port55_LED2_Active_B
(P55_Lane1_LED_B)
R/W
0
1: Port55_LED2_B Active ON
0: Port55_LED2_B Active OFF (Default)
4
Port55_LED2_Active_G
(P55_Lane1_LED_G)
R/W
0
1: Port55_LED2_G Active ON
0: Port55_LED2_G Active OFF (Default)
3
Port55_LED2_Active_R
(P55_Lane1_LED_R)
R/W
0
1: Port55_LED2_R Active ON
0: Port55_LED2_R Active OFF (Default)
2
Port55_LED2_B
(P55_Lane1_LED_B)
R/W
1
1: Port55_LED2_B LED OFF (Default)
0: Port55_LED2_B LED ON
1
Port55_LED2_G
(P55_Lane1_LED_G)
R/W
1
1: Port55_LED2_G LED OFF (Default)
0: Port55_LED2_G LED ON
0
Port55_LED2_R
(P55_Lane1_LED_R)
R/W
1
1: Port55_LED2_R LED OFF (Default)
0: Port55_LED2_R LED ON
5.12.6.39. Offset 0x4A QSFP28 RGB LED -27 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port55_LED3_Active_B
(P55_Lane2_LED_B)
R/W
0
1: Port55_LED3_B Active ON
0: Port55_LED3_B Active OFF (Default)
4
Port55_LED3_Active_G
(P55_Lane2_LED_G)
R/W
0
1: Port55_LED3_G Active ON
0: Port55_LED3_G Active OFF (Default)
3
Port55_LED3_Active_R
(P55_Lane2_LED_R)
R/W
0
1: Port55_LED3_R Active ON
0: Port55_LED3_R Active OFF (Default)
2
Port55_LED3_B
(P55_Lane2_LED_B)
R/W
1
1: Port55_LED3_B LED OFF (Default)
0: Port55_LED3_B LED ON
