Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
163
1
Port55_LED3_G
(P55_Lane2_LED_G)
R/W
1
1: Port55_LED3_G LED OFF (Default)
0: Port55_LED3_G LED ON
0
Port55_LED3_R
(P55_Lane2_LED_R)
R/W
1
1: Port55_LED3_R LED OFF (Default)
0: Port55_LED3_R LED ON
5.12.6.40. Offset 0x4B QSFP28 RGB LED -28 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port55_LED4_Active_B
(P55_Lane3_LED_B)
R/W
0
1: Port55_LED4_B Active ON
0: Port55_LED4_B Active OFF (Default)
4
Port55_LED4_Active_G
(P55_Lane3_LED_G)
R/W
0
1: Port55_LED4_G Active ON
0: Port55_LED4_G Active OFF (Default)
3
Port55_LED4_Active_R
(P55_Lane3_LED_R)
R/W
0
1: Port55_LED4_R Active ON
0: Port55_LED4_R Active OFF (Default)
2
Port55_LED4_B
(P55_Lane3_LED_B)
R/W
1
1: Port55_LED4_B LED OFF (Default)
0: Port55_LED4_B LED ON
1
Port55_LED4_G
(P55_Lane3_LED_G)
R/W
1
1: Port55_LED4_G LED OFF (Default)
0: Port55_LED4_G LED ON
0
Port55_LED4_R
(P55_Lane3_LED_R)
R/W
1
1: Port55_LED4_R LED OFF (Default)
0: Port55_LED4_R LED ON
5.12.6.41. Offset 0x4C QSFP28 RGB LED -29 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port56_LED1_Active_B
(P56_Lane3_LED_B)
R/W
0
1: Port56_LED1_B Active ON
0: Port56_LED1_B Active OFF (Default)
4
Port56_LED1_Active_G
(P56_Lane3_LED_G)
R/W
0
1: Port56_LED1_G Active ON
0: Port56_LED1_G Active OFF (Default)
3
Port56_LED1_Active_R
(P56_Lane3_LED_R)
R/W
0
1: Port56_LED1_R Active ON
0: Port56_LED1_R Active OFF (Default)
2
Port56_LED1_B
(P56_Lane3_LED_B)
R/W
1
1: Port56_LED1_B LED OFF (Default)
0: Port56_LED1_B LED ON
1
Port56_LED1_G
(P56_Lane3_LED_G)
R/W
1
1: Port56_LED1_G LED OFF (Default)
0: Port56_LED1_G LED ON
0
Port56_LED1_R
(P56_Lane3_LED_R)
R/W
1
1: Port56_LED1_R LED OFF (Default)
0: Port56_LED1_R LED ON
5.12.6.42. Offset 0x4D QSFP28 RGB LED -30 (Read& Write)
42
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
