Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
164
5
Port56_LED2_Active_B
(P56_Lane2_LED_B)
R/W
0
1: Port56_LED2_B Active ON
0: Port56_LED2_B Active OFF (Default)
4
Port56_LED2_Active_G
(P56_Lane2_LED_G)
R/W
0
1: Port56_LED2_G Active ON
0: Port56_LED2_G Active OFF (Default)
3
Port56_LED2_Active_R
(P56_Lane2_LED_R)
R/W
0
1: Port56_LED2_R Active ON
0: Port56_LED2_R Active OFF (Default)
2
Port56_LED2_B
(P56_Lane2_LED_B)
R/W
1
1: Port56_LED2_B LED OFF (Default)
0: Port56_LED2_B LED ON
1
Port56_LED2_G
(P56_Lane2_LED_G)
R/W
1
1: Port56_LED2_G LED OFF (Default)
0: Port56_LED2_G LED ON
0
Port56_LED2_R
(P56_Lane2_LED_R)
R/W
1
1: Port56_LED2_R LED OFF (Default)
0: Port56_LED2_R LED ON
5.12.6.43. Offset 0x4E QSFP28 RGB LED -31 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port56_LED3_Active_B
(P56_Lane1_LED_B)
R/W
0
1: Port56_LED3_B Active ON
0: Port56_LED3_B Active OFF (Default)
4
Port56_LED3_Active_G
(P56_Lane1_LED_G)
R/W
0
1: Port56_LED3_G Active ON
0: Port56_LED3_G Active OFF (Default)
3
Port56_LED3_Active_R
(P56_Lane1_LED_R)
R/W
0
1: Port56_LED3_R Active ON
0: Port56_LED3_R Active OFF (Default)
2
Port56_LED3_B
(P56_Lane1_LED_B)
R/W
1
1: Port56_LED3_B LED OFF (Default)
0: Port56_LED3_B LED ON
1
Port56_LED3_G
(P56_Lane1_LED_G)
R/W
1
1: Port56_LED3_G LED OFF (Default)
0: Port56_LED3_G LED ON
0
Port56_LED3_R
(P56_Lane1_LED_R)
R/W
1
1: Port56_LED3_R LED OFF (Default)
0: Port56_LED3_R LED ON
5.12.6.44. Offset 0x4F QSFP28 RGB LED -32 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port56_LED4_Active_B
(P56_Lane0_LED_B)
R/W
0
1: Port56_LED4_B Active ON
0: Port56_LED4_B Active OFF (Default)
4
Port56_LED4_Active_G
(P56_Lane0_LED_G)
R/W
0
1: Port56_LED4_G Active ON
0: Port56_LED4_G Active OFF (Default)
3
Port56_LED4_Active_R
(P56_Lane0_LED_R)
R/W
0
1: Port56_LED4_R Active ON
0: Port56_LED4_R Active OFF (Default)
2
Port56_LED4_B
(P56_Lane0_LED_B)
R/W
1
1: Port56_LED4_B LED OFF (Default)
0: Port56_LED4_B LED ON
