EDGECORE NETWORKS CORPORATION 2018
165
1
Port56_LED4_G
(P56_Lane0_LED_G)
R/W
1
1: Port56_LED4_G LED OFF (Default)
0: Port56_LED4_G LED ON
0
Port56_LED4_R
(P56_Lane0_LED_R)
R/W
1
1: Port56_LED4_R LED OFF (Default)
0: Port56_LED4_R LED ON
5.12.6.45. Offset 0x50 SFP+ RGB LED -1 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port57_Active_B
(SFP_FX0_LED_B)
R/W
0
1: Port57_B Active ON
0: Port57_B Active OFF (Default)
4
Port57_Active_G
(SFP_FX0_LED_G)
R/W
0
1: Port57_G Active ON
0: Port57_G Active OFF (Default)
3
Port57_Active_R
(SFP_FX0_LED_R)
R/W
0
1: Port57_R Active ON
0: Port57_R Active OFF (Default)
2
Port57_B
(SFP_FX0_LED_B)
R/W
1
1: Port57_B LED OFF (Default)
0: Port57_B LED ON
1
Port57_G
(SFP_FX0_LED_G)
R/W
1
1: Port57_G LED OFF (Default)
0: Port57_G LED ON
0
Port57_R
(SFP_FX0_LED_R)
R/W
1
1: Port57_R LED OFF (Default)
0: Port57_R LED ON
5.12.6.46. Offset 0x51 SFP+ RGB LED -2 (Read& Write)
Bit
Name
R/W
Reset Value
Description
7:6
Reserve
NA
NA
5
Port58_Active_B
(SFP_FX1_LED_B)
R/W
0
1: Port58_B Active ON
0: Port58_B Active OFF (Default)
4
Port58_Active_G
(SFP_FX1_LED_G)
R/W
0
1: Port58_G Active ON
0: Port58_G Active OFF (Default)
3
Port58_Active_R
(SFP_FX1_LED_R)
R/W
0
1: Port58_R Active ON
0: Port58_R Active OFF (Default)
2
Port58_B
(SFP_FX1_LED_B)
R/W
1
1: Port58_B LED OFF (Default)
0: Port58_B LED ON
1
Port58_G
(SFP_FX1_LED_G)
R/W
1
1: Port58_G LED OFF (Default)
0: Port58_G LED ON
0
Port58_R
(SFP_FX1_LED_R)
R/W
1
1: Port58_R LED OFF (Default)
0: Port58_R LED ON
5.12.6.47. Offset 0x60 MGMT LED (Read & Write)
Bit
Name
R/W
Reset Value
Description
7:2
Reserved
NA
NA
1
MGMT_ACT
R/W
1
1: There is no activity on the port. (Default)
