Edge-Core AS7326-56X Programming Guide

EDGECORE NETWORKS CORPORATION 2018
170
Address
Register
R/W
Default value
0x30
Fan Module Power
enable
Read& Write
0x3F
0x31
Watchdog timer
Read& Write
0x06
0x32
Watchdog
Maximum PWM
value
Read& Write
0x0F
0x33
Watchdog disable
Read& Write
0x01
0X42
Fan LED
Read& Write
0x00
0X43
Fan1 Vendor ID
Read Only
0x04
0X44
Fan2 Vendor ID
Read Only
0x04
0X45
Fan3 Vendor ID
Read Only
0x04
0X46
Fan4 Vendor ID
Read Only
0x04
0X47
Fan5 Vendor ID
Read Only
0x04
0X48
Fan6 Vendor ID
Read Only
0x04
5.12.8.1. Offset 0x00 Board Info (Read Only)
Bit
Name
R/W
Reset Value
Description
7:5
Version_ID[3:1]
R
000
100: R0A
101: R0B
110: R01
Others: Reserved
4:2
Reserved
N/A
NA
1:0
Board_ID[1:0]
R
11
00: Reserved
01: Reserved
10: Reserved
11: ZZ project
5.12.8.2. Offset 0x01 CPLD version (ReadOnly)
Bit
Name
R/W
Reset Value
Description
7:0
CPLD_ver[7:0]
R
0xD1
CPLD version
5.12.8.3. Offset 0x04 Fan CPLD Reset (Read & Write)
Bit
Name
R/W
Reset Value
Description
7
Reset_CPLD
R/W
1
1: CPLD is placed in normal operation state.
0: CPLD is placed in reset state.
6:0
Reserved
N/A
NA
5.12.8.4. Offset 0x05 Interrupt Status (Read Only)
Bit
Name
R/W
Reset Value
Description
7
Alarm_INTB_CPU
R
1
1: No interrupt
0: There is INTR to CPU
6:0
Reserved
N/A
NA
