5.12.8.5. Offset 0x06 Interrupt Mask (Read& Write)
1: CPLD blocks incoming the interrupt
0: CPLD passes the interrupt to CPU
5.12.8.6. Offset 0x0F Fan Module Present (Read Only)
1: Fan6 isn’t inserted
0: Fan6 is inserted
1: Fan5 isn’t inserted
0: Fan5 is inserted
1: Fan4 isn’t inserted
0: Fan4 is inserted
1: Fan3 isn’t inserted
0: Fan3 is inserted
1: Fan2 isn’t inserted
0: Fan2 is inserted
1: Fan1 isn’t inserted
0: Fan1 is inserted
5.12.8.7. Offset 0x10 Fan Module Direction (Read Only)
1: The air flow of Fan6 is “AFI-Back to Front”
0: The air flow of Fan6 is “AFO-Front to back”
1: The air flow of Fan6 is “AFI-Back to Front”
0: The air flow of Fan6 is “AFO-Front to back”
1: The air flow of Fan6 is “AFI-Back to Front”
0: The air flow of Fan6 is “AFO-Front to back”
1: The air flow of Fan6 is “AFI-Back to Front”
0: The air flow of Fan6 is “AFO-Front to back”
1: The air flow of Fan6 is “AFI-Back to Front”
0: The air flow of Fan6 is “AFO-Front to back”
1: The air flow of Fan6 is “AFI-Back to Front”
0: The air flow of Fan6 is “AFO-Front to back”
Fan pin13 indicate airflow direction.
AFI: Floating. (CPLD must pull hihg internal.)
AFO: Ground.
5.12.8.8. Offset 0x11 Fan Module PWM (Read& Write)
Duty cycle mapping refer to following table.
0000: 0x6.25% = 0% duty cycle
0001: 5x6.25% = 31.25% duty cycle
0010: 5x6.25% = 31.25% duty cycle
0011: 5x6.25% = 31.25% duty cycle
0100: 5x6.25% = 31.25% duty cycle
1000: 9x6.25% = 56.25% duty cycle
1001: 10x6.25% = 62.50% duty cycle
1010: 11x6.25% = 68.75% duty cycle
1011: 12x6.25% = 75.00% duty cycle
1100: 13x6.25% = 81.25% duty cycle
